The advantages of cooling system:

1. Atomized particles is very small, average diameter is 50-70 microns, guarantee that 100% of evaporation,will not wet the bottom side and wall.

2. Single nozzle-flow is large, water volume regulation ratio is 10:1, within the scope of the flow control, atomized particles diameter is remain basically unchanged.

3. Spraying coverage is large, the spray diameter up to 3-4 meters,is more advantageous to reduce flue gas temperature and tempering.

4. Cooling system operation cost is low, energy-saving significantly, general conditions required 3 to 5 bar air pressure,4 to 7 bar working pressure.

5. The nozzle aperture can up to 6.3 millimeters with excellent blockage resistance.

6. The nozzle has a variety of corrosion resistant material selections, can be used in different difficult working environments for 3 to 5 years.

7. The cooling system has automatic mode, bypass mode and stop working mode, guaranteeing the safe and reliable operation of the cooling system, reduce the manual operation.

8. The cooling system parts will chosen from durable, easy to maintain high quality components, to ensure safe and reliable operation,reduce the maintenance of the cooling system to the greatest extent possible.

The cooling system in the following fields are mature applications:
Blast furnace gas reduce temperature and cooling.
Cooling for converter gas dry dust removal.
Evaporative cooling of electric furnace flue gas.

Humidifying tower of cement’s dry normals production/humidification and cooling the flue gas from pipes.
Kiln head humidification and cooling of cement’s dry normals.
Quenching tower of solid waste incineration high temperature smoke spray evaporative cooling.
Spray evaporative cooling high temperature non-ferrous smelting arsenic in quench.
Coal fired/fuel oil boiler half dry normals spray desulfurization.
Cooling the accident of power station boiler flue gas.
Half dry normals smoke desulfurization,denitrification and acid,etc.
